FM62-Pelton-Turbine

Model：FM62

Use：A small-scale Pelton turbine unit which is designed to be used in conjunction with the FM6X service unit. A Pelton turbine uses the momentum transferred from the impact of a jet of water onto its buckets to generate power.

Standard：

Related Products
Product Detail
Project Case
TAG

Description

A small-scale Pelton turbine unit which is designed to be used in conjunction with the FM6X service unit. A Pelton turbine uses the momentum transferred from the impact of a jet of water onto its buckets to generate power.

The FM62 consists of an inlet manifold which supplies water to a spear valve that allows users to vary the jet cross section while maintaining the water velocity.

The runner itself is mounted in a clear acrylic enclosure to allow maximum visibility of the workings.

The unit incorporates a pressure sensor to measure the inlet condition of the water. This pressure can be accurately controlled using the software supplied with the service unit.


Demonstration Capabilities


  • Determining the characteristics of the Pelton Turbine, including the relationships of:

    • volume flow rate

    • head

    • torque produced

    • power output

    • efficiency to rotational speed

  • Comparison of throttle control and spear valve control of a Pelton turbine
